Board-to-Board Solutions

Picture for category Board-to-Board Solutions

A ‘Board-to-Board’ (or B2B) RF connection is defined as a means for transmitting an RF signal between two parallel RF printed circuit boards (PCB) using RF connectors. SV offers a complete line of SMP and SMPM PCB connectors that are ideal for creating a B2B connection. This configuration consists of two PCB surface mount male connectors and a female-female adapter, or “bullet.” Learn how to create an ideal B2B solution in our Board-to-Board RF Connector Solutions Product Portfolio

Application Note

Board-to-Board Solutions

SMP

Impedance (Ω)50
Frequency GHz40 GHz
Shielding Effectiveness≥ -80 dB DC - 3 GHz
 ≥ -65 dB 3 - 26.5 GHz
Dielectric withstanding Voltage500 VRMS
Mating Cycles - SB1000
Mating Cycles - LD500
Mating Cycles - FD100
Insertion Force - SB3.0 lbs
Insertion Force - LD5.0 lbs
Insertion Force - FD7.0 lbs
Withdrawal Force - SB0.5 lbs
Withdrawal Force - LD7.0 lbs
Withdrawal Force - FD9.0 lbs
Axial Misalignment.010” Max
Radial Misalignment3° Max
Temperature Rating-65°C to +165°C
Corrosion (salt spray)MIL-STD-202, Method 101, Condition B
VibrationMIL-STD-202, Method 204, Condition D
ShockMIL-STD-202, Method 213, Condition I
Thermal ShockMIL-STD-202, Method 107, Condition B
Moisture ResistanceMIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude)MIL-STD-202, Method 105, Condition C, 70k Ft.

SMPM

Impedance (Ω)50
Frequency GHz65 GHz
Shielding Effectiveness≥ -80 dB DC - 3 GHz
 ≥ -65 dB 3 - 26.5 GHz
Dielectric withstanding Voltage325 VRMS
Mating Cycles - SB500
Mating Cycles - FD100
Insertion Force - SB2.5 lbs
Insertion Force - FD4.5 lbs
Withdrawal Force - SB1.5 lbs
Withdrawal Force - FD6.5 lbs
Axial Misalignment.010” Max
Radial Misalignment3° Max
Temperature Rating-65°C to +165°C
Corrosion (salt spray)MIL-STD-202, Method 101, Condition B
VibrationMIL-STD-202, Method 204, Condition D
ShockMIL-STD-202, Method 213, Condition I
Thermal ShockMIL-STD-202, Method 107, Condition B
Moisture ResistanceMIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude)MIL-STD-202, Method 105, Condition C, 70k Ft.
Filters
per page
Part #   1290-4008

SMP Female to Female Bullet (OAL .255")"

Available Inventory: 5355
1290-4008
SMP Adapters 1290-4008
Datasheet
Part #   1112-4186

SMP Female to Female Bullet (OAL .265”)

Available Inventory: 0
1112-4186
SMP Adapters 1112-4186
Datasheet
Part #   1112-4187

SMP Female to Female Bullet (OAL .275”)

Available Inventory: 0
1112-4187
SMP Adapters 1112-4187
Datasheet
Part #   1112-4188

SMP Female to Female Bullet (OAL .285”)

Available Inventory: 0
1112-4188
SMP Adapters 1112-4188
Datasheet
Part #   1112-4189

SMP Female to Female Bullet (OAL .295”)

Available Inventory: 0
1112-4189
SMP Adapters 1112-4189
Datasheet
Part #   1290-4009

SMP Female to Female Bullet (OAL 0.396")"

Available Inventory: 19
1290-4009
SMP Adapters 1290-4009
Datasheet
Part #   1290-4007

SMP Female to Female Bullet (OAL 0.769")"

Available Inventory: 348
1290-4007
SMP Adapters 1290-4007
Datasheet
Part #   1112-4144

SMP Female to Female Bullet, Spring Loaded (OAL 0.650")

Available Inventory: 299
1112-4144
SMP Adapters 1112-4144
Datasheet
Part #   1112-4145

SMP Female to Female Bullet, Spring Loaded (OAL 0.725")"

Available Inventory: 456
1112-4145
SMP Adapters 1112-4145
Datasheet
Part #   1112-4146

SMP Female to Female Bullet, Spring Loaded (OAL 0.800")"

Available Inventory: 168
1112-4146
SMP Adapters 1112-4146
Datasheet
Part #   1112-4147

SMP Female to Female Bullet, Spring Loaded (OAL 0.875")"

Available Inventory: 249
1112-4147
SMP Adapters 1112-4147
Datasheet
Part #   1112-4148

SMP Female to Female Bullet, Spring Loaded (OAL 0.950")"

Available Inventory: 99
1112-4148
SMP Adapters 1112-4148
Datasheet
Part #   1211-60211

SMP Male PCB Edge Launch Connector (Pre-Tinned), FD

Available Inventory: 315
1211-60211
SMP Connectors 1211-60211
Datasheet
Part #   1211-60209

SMP Male PCB Edge Launch Connector (Pre-Tinned), SB

Available Inventory: 126
1211-60209
SMP Connectors 1211-60209
Datasheet
Part #   1285-6002

SMP Male PCB Edge Launch Connector, .062" PCB Thickness, FD"

Available Inventory: 2091
1285-6002
SMP Connectors 1285-6002
Datasheet
Part #   1285-6003

SMP Male PCB Edge Launch Connector, .062" PCB Thickness, LD"

Available Inventory: 59
1285-6003
SMP Connectors 1285-6003
Datasheet
Part #   1285-6004

SMP Male PCB Edge Launch Connector, .062" PCB Thickness, SB"

Available Inventory: 48
1285-6004
SMP Connectors 1285-6004
Datasheet
Part #   9311-60035

SMP Male PCB Edge Launch Connector, 2 Port, FD

Available Inventory: 75
9311-60035
SMP Connectors 9311-60035
Datasheet
Part #   9311-60034

SMP Male PCB Edge Launch Connector, 2 Port, LD

Available Inventory: 100
9311-60034
SMP Connectors 9311-60034
Datasheet
Part #   9311-60033

SMP Male PCB Edge Launch Connector, 2 Port, SB

Available Inventory: 96
9311-60033
SMP Connectors 9311-60033
Datasheet
Part #   9311-60038

SMP Male PCB Edge Launch Connector, 4 Port, FD

Available Inventory: 166
9311-60038
SMP Connectors 9311-60038
Datasheet
Part #   9311-60037

SMP Male PCB Edge Launch Connector, 4 Port, LD

Available Inventory: 77
9311-60037
SMP Connectors 9311-60037
Datasheet
Part #   9311-60036

SMP Male PCB Edge Launch Connector, 4 Port, SB

Available Inventory: 94
9311-60036
SMP Connectors 9311-60036
Datasheet
Part #   1211-66175

SMP Male PCB Edge Launch Connector, CM

Available Inventory: 549
1211-66175
SMP Connectors 1211-66175
Datasheet
Part #   1211-66137

SMP Male PCB Edge Launch Connector, FD

Available Inventory: 1964
1211-66137
SMP Connectors 1211-66137
Datasheet
Part #   1211-66138

SMP Male PCB Edge Launch Connector, LD

Available Inventory: 1254
1211-66138
SMP Connectors 1211-66138
Datasheet
Part #   1211-66139

SMP Male PCB Edge Launch Connector, SB

Available Inventory: 984
1211-66139
SMP Connectors 1211-66139
Datasheet
Part #   1211-66195

SMP Male PCB QB Edge Launch Connector, SB

Available Inventory: 869
1211-66195
SMP Connectors 1211-66195
Datasheet
Part #   1211-40032

SMP Male PCB QB Surface Mount Connector

Available Inventory: 86
1211-40032
SMP Connectors 1211-40032
Datasheet
Part #   1211-20016

SMP Male PCB Surface Mount Connector (Glass Seal), FD

Available Inventory: 38
1211-20016
SMP Connectors 1211-20016
Datasheet
Part #   1211-20015

SMP Male PCB Surface Mount Connector (Glass Seal), SB

Available Inventory: 93
1211-20015
SMP Connectors 1211-20015
Datasheet
1211-20021
SMP Connectors 1211-20021
Datasheet
1211-20019
SMP Connectors 1211-20019
Datasheet
Part #   1211-40089

SMP Male PCB Surface Mount Connector (Pre-Tinned), R/A, FD

Available Inventory: 384
1211-40089
SMP Connectors 1211-40089
Datasheet
Part #   1211-40087

SMP Male PCB Surface Mount Connector (Pre-Tinned), R/A, SB

Available Inventory: 198
1211-40087
SMP Connectors 1211-40087
Datasheet
Part #   1211-40162

SMP Male PCB Surface Mount Connector (Reflow Stable), FD

Available Inventory: 180
1211-40162
SMP Connectors 1211-40162
Datasheet
Part #   9311-00035

SMP Male PCB Surface Mount Connector, 2 Port, SB

Available Inventory: 48
9311-00035
SMP Connectors 9311-00035
Datasheet
Part #   9311-00036

SMP Male PCB Surface Mount Connector, 4 Port, SB

Available Inventory: 84
9311-00036
SMP Connectors 9311-00036
Datasheet
Part #   1211-40003

SMP Male PCB Surface Mount Connector, R/A, FD

Available Inventory: 1518
1211-40003
SMP Connectors 1211-40003
Datasheet
Part #   1211-40004

SMP Male PCB Surface Mount Connector, R/A, LD

Available Inventory: 224
1211-40004
SMP Connectors 1211-40004
Datasheet
Part #   1211-40001

SMP Male PCB Surface Mount Connector, R/A, SB

Available Inventory: 1651
1211-40001
SMP Connectors 1211-40001
Datasheet
Part #   1211-40116

SMP Male PCB Thru-Hole Connector (Pre-Tinned), FD

Available Inventory: 200
1211-40116
SMP Connectors 1211-40116
Datasheet
Part #   1211-40172

SMP Male PCB Thru-Hole Connector (Pre-Tinned), FD

Available Inventory: 108
1211-40172
SMP Connectors 1211-40172
Datasheet
Part #   1211-40082

SMP Male PCB Thru-Hole Connector (Pre-Tinned), R/A, FD

Available Inventory: 54
1211-40082
SMP Connectors 1211-40082
Datasheet
Part #   1211-40080

SMP Male PCB Thru-Hole Connector (Pre-Tinned), R/A, SB

Available Inventory: 229
1211-40080
SMP Connectors 1211-40080
Datasheet
Part #   1211-40170

SMP Male PCB Thru-Hole Connector (Pre-Tinned), SB

Available Inventory: 145
1211-40170
SMP Connectors 1211-40170
Datasheet
Part #   1211-40169

SMP Male PCB Thru-Hole Connector, FD

Available Inventory: 150
1211-40169
SMP Connectors 1211-40169
Datasheet
Part #   1211-40113

SMP Male PCB Thru-Hole Connector, FD

Available Inventory: 169
1211-40113
SMP Connectors 1211-40113
Datasheet
Part #   1211-40110

SMP Male PCB Thru-Hole Connector, R/A, FD

Available Inventory: 225
1211-40110
SMP Connectors 1211-40110
Datasheet
Part #   1212-60062

SMP Male PCB Thru-Hole Connector, R/A, FD

Available Inventory: 94
1212-60062
SMP Connectors 1212-60062
Datasheet
Part #   1212-60060

SMP Male PCB Thru-Hole Connector, R/A, SB

Available Inventory: 150
1212-60060
SMP Connectors 1212-60060
Datasheet
Part #   1211-40108

SMP Male PCB Thru-Hole Connector, R/A, SB

Available Inventory: 146
1211-40108
SMP Connectors 1211-40108
Datasheet
Part #   SF1212-6002

SMP Male PCB Thru-Hole Connector, R/A, SB

Available Inventory: 68
SF1212-6002
SMP Connectors SF1212-6002
Datasheet
Part #   1211-40167

SMP Male PCB Thru-Hole Connector, SB

Available Inventory: 138
1211-40167
SMP Connectors 1211-40111
Datasheet
Part #   1132-4010

SMPM Female to Female Bullet (OAL 0.166")"

Available Inventory: 2901
1132-4010
SMPM Adapters 1132-4010
Datasheet
Part #   1132-4021

SMPM Female to Female Bullet (OAL 0.180")"

Available Inventory: 1186
1132-4021
SMPM Adapters 1132-4021
Datasheet
Part #   1132-4169

SMPM Female to Female Bullet (OAL 0.188")

Available Inventory: 0
1132-4169
SMPM Adapters 1132-4169
Datasheet
Part #   1132-4170

SMPM Female to Female Bullet (OAL 0.197")

Available Inventory: 0
1132-4170
SMPM Adapters 1132-4170
Datasheet
Part #   3290-4002

SMPM Female to Female Bullet (OAL 0.211")"

Available Inventory: 1303
3290-4002
SMPM Adapters 3290-4002
Datasheet
Part #   3290-4003

SMPM Female to Female Bullet (OAL 0.327")"

Available Inventory: 237
3290-4003
SMPM Adapters 3290-4003
Datasheet
Part #   1132-4006

SMPM Female to Female Bullet, Spring Loaded (OAL 0.412")"

Available Inventory: 617
1132-4006
SMPM Adapters 1132-4006
Datasheet
Part #   1132-4113

SMPM Female to Female Bullet, Spring Loaded (OAL 0.600")

Available Inventory: 58
1132-4113
SMPM Adapters 1132-4113
Datasheet
Part #   1132-4114

SMPM Female to Female Bullet, Spring Loaded (OAL 0.690")

Available Inventory: 51
1132-4114
SMPM Adapters 1132-4114
Datasheet
Part #   1132-4115

SMPM Female to Female Bullet, Spring Loaded (OAL 0.780")

Available Inventory: 66
1132-4115
SMPM Adapters 1132-4115
Datasheet
Part #   1132-4116

SMPM Female to Female Bullet, Spring Loaded (OAL 0.870")

Available Inventory: 124
1132-4116
SMPM Adapters 1132-4116
Datasheet
Part #   1132-4117

SMPM Female to Female Bullet, Spring Loaded (OAL 0.960")

Available Inventory: 234
1132-4117
SMPM Adapters 1132-4117
Datasheet
Part #   1132-4139

SMPM Female to Female Non-Magnetic Bullet (OAL 0.180)

Available Inventory: 83
1132-4139
SMPM Adapters 1132-4139
Datasheet
Part #   1132-4140

SMPM Female to Female Non-Magnetic Bullet (OAL 0.327)

Available Inventory: 122
1132-4140
SMPM Adapters 1132-4140
Datasheet
Part #   3211-40119

SMPM Male Non-Magnetic PCB Surface Mount Connector, FD

Available Inventory: 65
3211-40119
SMPM Connectors 3211-40119
Datasheet
Part #   3211-40118

SMPM Male Non-Magnetic PCB Surface Mount Connector, SB

Available Inventory: 209
3211-40118
SMPM Connectors 3211-40118
Datasheet
Part #   3211-60308

SMPM Male PCB Edge Launch Connector (Pre-Tinned), FD

Available Inventory: 419
3211-60308
SMPM Connectors 3211-60308
Datasheet
Part #   3211-60307

SMPM Male PCB Edge Launch Connector (Pre-Tinned), SB

Available Inventory: 221
3211-60307
SMPM Connectors 3211-60307
Datasheet
Part #   3211-60087

SMPM Male PCB Edge Launch Connector, 2 Port, FD

Available Inventory: 360
3211-60087
SMPM Connectors 3211-60087
Datasheet
Part #   3211-60086

SMPM Male PCB Edge Launch Connector, 2 Port, SB

Available Inventory: 94
3211-60086
SMPM Connectors 3211-60086
Datasheet
Part #   9311-60039

SMPM Male PCB Edge Launch Connector, 4 Port, FD

Available Inventory: 555
9311-60039
SMPM Connectors 9311-60039
Datasheet
Part #   9311-60015

SMPM Male PCB Edge Launch Connector, 4 Port, SB

Available Inventory: 200
9311-60015
SMPM Connectors 9311-60015
Datasheet
Part #   3211-60180

SMPM Male PCB Edge Launch Connector, 8 Port, CM

Available Inventory: 50
3211-60180
SMPM Connectors 3211-60180
Datasheet
Part #   3211-60181

SMPM Male PCB Edge Launch Connector, 8 Port, FD

Available Inventory: 30
3211-60181
SMPM Connectors 3211-60181
Datasheet
Part #   3285-6001

SMPM Male PCB Edge Launch Connector, FD

Available Inventory: 2562
3285-6001
SMPM Connectors 3285-6001
Datasheet
Part #   3211-60035

SMPM Male PCB Edge Launch Connector, SB

Available Inventory: 2580
3211-60035
SMPM Connectors 3211-60035
Datasheet
Part #   3211-60118

SMPM Male PCB QB Edge Launch Connector, SB

Available Inventory: 1909
3211-60118
SMPM Connectors 3211-60118
Datasheet
Part #   3211-60112

SMPM Male PCB QB Surface Mount Connector, R/A

Available Inventory: 220
3211-60112
SMPM Connectors 3211-60112
Datasheet
Part #   3211-20028

SMPM Male PCB Surface Mount Connector (Glass Seal), FD

Available Inventory: 113
3211-20028
SMPM Connectors 3211-20028
Datasheet
Part #   3211-20027

SMPM Male PCB Surface Mount Connector (Glass Seal), SB

Available Inventory: 0
3211-20027
SMPM Connectors 3211-20027
Datasheet
3211-20034
SMPM Connectors 3211-20034
Datasheet
3211-20033
SMPM Connectors 3211-20033
Datasheet
Part #   3211-40107

SMPM Male PCB Surface Mount Connector (Pre-Tinned), R/A, FD

Available Inventory: 188
3211-40107
SMPM Connectors 3211-40107
Datasheet
Part #   3211-40106

SMPM Male PCB Surface Mount Connector (Pre-Tinned), R/A, SB

Available Inventory: 551
3211-40106
SMPM Connectors 3211-40106
Datasheet
Part #   3211-40175

SMPM Male PCB Surface Mount Connector (Reflow Stable), FD

Available Inventory: 190
3211-40175
SMPM Connectors 3211-40175
Datasheet
Part #   9311-00037

SMPM Male PCB Surface Mount Connector, 2 Port, SB

Available Inventory: 114
9311-00037
SMPM Connectors 9311-00037
Datasheet
Part #   9311-00038

SMPM Male PCB Surface Mount Connector, 4 Port, SB

Available Inventory: 232
9311-00038
SMPM Connectors 9311-00038
Datasheet
Part #   3287-6100

SMPM Male PCB Surface Mount Connector, R/A, FD

Available Inventory: 3114
3287-6100
SMPM Connectors 3287-6100
Datasheet
Part #   3287-6101

SMPM Male PCB Surface Mount Connector, R/A, SB

Available Inventory: 1838
3287-6101
SMPM Connectors 3287-6101
Datasheet
Part #   3211-40143

SMPM Male PCB Thru-Hole Connector (Pre-Tinned), FD

Available Inventory: 190
3211-40143
SMPM Connectors 3211-40143
Datasheet
Part #   3211-40094

SMPM Male PCB Thru-Hole Connector (Pre-Tinned), R/A, FD

Available Inventory: 689
3211-40094
SMPM Connectors 3211-40094
Datasheet
Part #   3211-40093

SMPM Male PCB Thru-Hole Connector (Pre-Tinned), R/A, SB

Available Inventory: 1
3211-40093
SMPM Connectors 3211-40093
Datasheet
Part #   3211-40142

SMPM Male PCB Thru-Hole Connector (Pre-Tinned), SB

Available Inventory: 181
3211-40142
SMPM Connectors 3211-40142
Datasheet
Part #   3211-40024

SMPM Male PCB Thru-Hole Connector, 2 Port, R/A, FD

Available Inventory: 21
3211-40024
SMPM Connectors 3211-40024
Datasheet
Part #   3287-4100

SMPM Male PCB Thru-Hole Connector, FD

Available Inventory: 1798
3287-4100
SMPM Connectors 3287-4100
Datasheet
Part #   3211-40141

SMPM Male PCB Thru-Hole Connector, FD

Available Inventory: 42
3211-40141
SMPM Connectors 3211-40141
Datasheet
Part #   3211-40139

SMPM Male PCB Thru-Hole Connector, R/A, FD

Available Inventory: 243
3211-40139
SMPM Connectors 3211-40139
Datasheet
Part #   3212-40002

SMPM Male PCB Thru-Hole Connector, R/A, FD

Available Inventory: 934
3212-40002
SMPM Connectors 3212-40002
Datasheet
Part #   SF3211-60033

SMPM Male PCB Thru-Hole Connector, R/A, FD

Available Inventory: 631
SF3211-60033
SMPM Connectors SF3211-60033
Datasheet
Part #   SF3211-60034

SMPM Male PCB Thru-Hole Connector, R/A, SB

Available Inventory: 142
SF3211-60034
SMPM Connectors SF3211-60034
Datasheet
Part #   3212-40003

SMPM Male PCB Thru-Hole Connector, R/A, SB

Available Inventory: 180
3212-40003
SMPM Connectors 3212-40003
Datasheet
Part #   3211-40138

SMPM Male PCB Thru-Hole Connector, R/A, SB

Available Inventory: 281
3211-40138
SMPM Connectors 3211-40138
Datasheet
Part #   3211-40140

SMPM Male PCB Thru-Hole Connector, SB

Available Inventory: 178
3211-40140
SMPM Connectors 3211-40140
Datasheet
Part #   3287-4101

SMPM Male PCB Thru-Hole Connector, SB

Available Inventory: 135
3287-4101
SMPM Connectors 3287-4101
Datasheet
SF3211-60218
SMPM Connectors SF3211-60218
Datasheet
SF3211-60193
SMPM Connectors SF3211-60193
Datasheet
SF3211-60218-1S
SMPM Connectors SF3211-60218-1S
Datasheet
SF3211-60193-1S
SMPM Connectors SF3211-60193-1S
Datasheet
SF3211-60218-2S
SMPM Connectors SF3211-60218-2S
Datasheet
SF3211-60193-2S
SMPM Connectors SF3211-60193-2S
Datasheet
Part #   3811-40092

SMPS Male PCB Surface Mount Connector (Reflow Stable) (.009"), FD

Available Inventory: 150
3811-40092
SMPS Connectors 3811-40092
Datasheet
Part #   3211-40170

Threaded SMPM Male PCB Edge Launch Connector (Pre-Tinned), SB

Available Inventory: 117
3211-40170
SMPM Connectors 3211-40170
Datasheet
Part #   3211-40121

Threaded SMPM Male PCB Edge Launch Connector, SB

Available Inventory: 577
3211-40121
SMPM Connectors 3211-40121
Datasheet
Part #   3212-60037

Threaded SMPM Male PCB Thru-Hole Connector (Pre-Tinned), R/A, SB

Available Inventory: 136
3212-60037
SMPM Connectors 3212-60037
Datasheet
Part #   3211-60298

Threaded SMPM Male PCB Thru-Hole Connector, SB

Available Inventory: 951
3211-60298
SMPM Connectors 3211-60298
Datasheet
3211-60407-1S
SMPM Connectors 3211-60407-1S
Datasheet
3211-60407-2S
SMPM Connectors 3211-60407-2S
Datasheet
Filters Clear All
