Products specifications
| Attribute name | Attribute value |
|---|---|
| RF Series | SMA |
| RF Series 2 | NSME |
| Gender | Socket |
| Orientation (Body) | Straight |
| Coupling | Threaded |
| Mounting Type | D38999 Series I, II, III and IV |
| Style | Size 8 |
| Finish | Passivated |
| Electrical | |
| Impedance | 50 ohms |
| Frequency | 3 GHz |
| Mechanical | |
| Mating Cycles | 500 |
| Environmental | |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Shock | MIL-STD-202, Method 213, Condition I |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
This information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge based on the information they provided. Please contact compliance@svmicro.com for any Compliance or Environmental related questions. Last Update: 1/30/2026 1:21:13 AM |
