Attribute name | Attribute value |
---|---|
Style | Size 8 |
Mounting Type | D38999 Series I, III and IV |
RF Series | BMB |
Gender | Socket |
Orientation (Body) | Straight |
Coupling | Push-on |
Termination Style | Solder |
RF Series 2 | VITA SMPM |
Gender 2 | Jack (Female) |
Orientation 2 (Body) | Straight |
Cable Type | 0.085 Flexible Coax |
Cable Length | 12" |
Family | VITA 67, SOSA Aligned |
Electrical | |
Frequency | 22 GHz |
Impedance | 50 ohms |
Shielding Effectiveness | ≥ -100 dB, DC to 26.5 GHz |
Dielectric withstanding Voltage | 325 VRMS |
Mechanical | |
Withdrawal Force | 1.5 lbs |
Mating Cycles | 500 |
Insertion Force | 2.5 lbs (per contact) |
Environmental | |
Temperature Rating | -65°C to +165°C |
Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
Shock | MIL-STD-202, Method 213, Condition I |
Vibration | MIL-STD-202, Method 204, Condition D |
Thermal Shock | MIL-STD-202, Method 107, Condition B |
Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
